uniapp+vue3+ts签字上传

文章索引

代码

<template>
  <view class="confirm-page">
    <view class="sign-box">
      <view class="canvas">
        <canvas
          canvas-id="canvas"
          @touchstart="onTouchstart"
          @touchmove="onTouchmove"
          @touchend="onTouchend"
        ></canvas>
      </view>
      <view class="sign-actions">
        <view class="sign-finish" @click="onFinish">完成</view>
        <view class="sign-clear" @click="onClear">清除</view>
      </view>
    </view>
  </view>
</template>
<script setup lang="ts">
  import useUploadImage from '@/composition/uploadImage'

  type DataType = {
    ctx: UniApp.CanvasContext
    points: { x: number; y: number }[]
    flag: boolean
    canvasImg: string
  }
  const data = reactive<DataType>({
    ctx: uni.createCanvasContext('canvas'),
    points: [],
    flag: false,
    canvasImg: ''
  })

  // 手写签名
  const signImageList = ref<{ uri: string; url: string }[]>([])
  const signImage = useUploadImage(signImageList)

  onLoad(() => {
    data.ctx.lineWidth = 4
    data.ctx.lineCap = 'round'
    data.ctx.lineJoin = 'round'
  })

  // 触摸开始，获取到起点
  const onTouchstart = e => {
    const startX = e.changedTouches[0].x
    const startY = e.changedTouches[0].y
    const startPoint = { x: startX, y: startY }

    data.points.push(startPoint)

    // 每次触摸开始，开启新的路径
    data.ctx.beginPath()
  }

  // 触摸移动，获取到路径点
  const onTouchmove = e => {
    const { x, y } = e.changedTouches[0]
    const movePoint = { x, y }
    data.points.push(movePoint)

    if (data.points.length >= 2) {
      draw() // 绘制路径
    }
  }

  // 触摸结束，将未绘制的点清空防止对后续路径产生干扰
  const onTouchend = () => {
    data.points = []
  }

  /**
   * 绘制笔迹
   * 1. 为保证笔迹实时显示，必须在移动的同时绘制笔迹
   * 2. 为保证笔迹连续，每次从路径集合中取两个点作为起点(moveTo)和终点(lineTo)
   * 3. 将上一次的终点作为下一次绘制的起点（即清除第一个点）
   */
  const draw = () => {
    data.flag = true
    const point1 = data.points[0]
    const point2 = data.points[1]
    data.points.shift()
    data.ctx.moveTo(point1.x, point1.y)
    data.ctx.lineTo(point2.x, point2.y)
    data.ctx.stroke()
    data.ctx.draw(true)
  }

  // 完成绘画
  const onFinish = () => {
    if (!data.flag) {
      uni.showToast({
        title: '请先签字',
        icon: 'none'
      })
      return
    }

    uni.canvasToTempFilePath({
      x: 0,
      y: 0,
      canvasId: 'canvas',
      success: function (res) {
        uni.getFileSystemManager().readFile({
          filePath: res.tempFilePath,
          encoding: 'base64',
          success: res => {
            data.canvasImg = base64
            console.log(base64)

            // eslint-disable-next-line @typescript-eslint/ban-ts-comment
            // @ts-expect-error
            const buffer = uni.base64ToArrayBuffer(res.data)

            // eslint-disable-next-line @typescript-eslint/ban-ts-comment
            // @ts-expect-error
            const filePath = wx.env.USER_DATA_PATH + '/sign.png'
            const fs = uni.getFileSystemManager()

            fs.writeFile({
              filePath,
              data: buffer,
              encoding: 'utf8',
              success(res) {
                console.log(res)
                signImage.uploadFilePromise(filePath).then(res => {
                  signImageList.value = [
                    {
                      url: res.uri,
                      uri: res.url
                    }
                  ]
                })
              },
              fail(res) {
                console.error(res)
              }
            })
          }
        })
      }
    })
  }

  // 清空画布
  const onClear = () => {
    data.flag = false
    uni.getSystemInfo({
      success: function (res) {
        const width = res.windowWidth
        const height = res.windowHeight
        data.ctx.clearRect(0, 0, width, height)
        data.ctx.draw(true)
      }
    })
  }
</script>
<style lang="scss" scoped>
  .sign-box {
    @apply bg-white;
  }
  .sign-actions {
    @apply flex justify-center items-center;

    view {
      @apply w-1/2 text-center py-2 text-white;

      &.sign-finish {
        @apply bg-blue-500;
      }
      &.sign-clear {
        @apply bg-red-500;
      }
    }
  }
</style>

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

<canvas

canvas-id="canvas"

@touchstart="onTouchstart"

@touchmove="onTouchmove"

@touchend="onTouchend"

></canvas>

</view>

</view>

</template>

import useUploadImage from '@/composition/uploadImage'

type DataType = {

ctx: UniApp.CanvasContext

points: { x: number; y: number }[]

flag: boolean

canvasImg: string

}

const data = reactive<DataType>({

ctx: uni.createCanvasContext('canvas'),

points: [],

flag: false,

canvasImg: ''

})

// 手写签名

const signImageList = ref<{ uri: string; url: string }[]>([])

const signImage = useUploadImage(signImageList)

onLoad(() => {

data.ctx.lineWidth = 4

data.ctx.lineCap = 'round'

data.ctx.lineJoin = 'round'

})

// 触摸开始，获取到起点

const onTouchstart = e => {

const startX = e.changedTouches[0].x

const startY = e.changedTouches[0].y

const startPoint = { x: startX, y: startY }

data.points.push(startPoint)

// 每次触摸开始，开启新的路径

data.ctx.beginPath()

}

// 触摸移动，获取到路径点

const onTouchmove = e => {

const { x, y } = e.changedTouches[0]

const movePoint = { x, y }

data.points.push(movePoint)

if (data.points.length >= 2) {

draw() // 绘制路径

}

// 触摸结束，将未绘制的点清空防止对后续路径产生干扰

const onTouchend = () => {

data.points = []

}

/**

* 绘制笔迹

* 1. 为保证笔迹实时显示，必须在移动的同时绘制笔迹

* 2. 为保证笔迹连续，每次从路径集合中取两个点作为起点(moveTo)和终点(lineTo)

* 3. 将上一次的终点作为下一次绘制的起点（即清除第一个点）

const draw = () => {

data.flag = true

const point1 = data.points[0]

const point2 = data.points[1]

data.points.shift()

data.ctx.moveTo(point1.x, point1.y)

data.ctx.lineTo(point2.x, point2.y)

data.ctx.stroke()

data.ctx.draw(true)

}

// 完成绘画

const onFinish = () => {

if (!data.flag) {

uni.showToast({

title: '请先签字',

icon: 'none'

})

return

}

uni.canvasToTempFilePath({

x: 0,

y: 0,

canvasId: 'canvas',

success: function (res) {

uni.getFileSystemManager().readFile({

filePath: res.tempFilePath,

encoding: 'base64',

success: res => {


data.canvasImg = base64

console.log(base64)

// eslint-disable-next-line @typescript-eslint/ban-ts-comment

// @ts-expect-error

const buffer = uni.base64ToArrayBuffer(res.data)

// eslint-disable-next-line @typescript-eslint/ban-ts-comment

// @ts-expect-error

const filePath = wx.env.USER_DATA_PATH + '/sign.png'

const fs = uni.getFileSystemManager()

fs.writeFile({

filePath,

data: buffer,

encoding: 'utf8',

success(res) {

console.log(res)

signImage.uploadFilePromise(filePath).then(res => {

signImageList.value = [

{

url: res.uri,

uri: res.url

}

]

})

fail(res) {

console.error(res)

}

})

}

})

}

})

}

// 清空画布

const onClear = () => {

data.flag = false

uni.getSystemInfo({

success: function (res) {

const width = res.windowWidth

const height = res.windowHeight

data.ctx.clearRect(0, 0, width, height)

data.ctx.draw(true)

}

})

}

</script>

.sign-box {

@apply bg-white;

}

.sign-actions {

@apply flex justify-center items-center;

view {

@apply w-1/2 text-center py-2 text-white;

&.sign-finish {

@apply bg-blue-500;

}

&.sign-clear {

@apply bg-red-500;

}

</style>

北鱼IT

uniapp+vue3+ts签字上传

代码

效果
